Workflow Template

The interfaces related to workflow templates allow users to generate diagrams using a predefined series of templates, requiring only simple modifications to a few parameters within the template.

Get Workflow Template​

  • Request Parameter Example: Replace the following parameters in the URL path.

    template_id: 676018193025756628

    Response (Including all fields that need to be modified) :

    {
      "templateId": "676018193025756628",
      "name": "二次元转真实",
      "fields": {
        "fieldAttrs": [
          {
            "nodeId": "25",
            "fieldName": "image",
            "fieldValue": ""
          },
          {
            "nodeId": "27",
            "fieldName": "text",
            "fieldValue": "1 girl"
          }
        ]
      }
    }

Check Workflow Template Parameters​

This interface first retrieves the workflow template, then replaces the fields corresponding to the request parameters in the obtained template (specifically, replacing the field_value in the node_id corresponding to field with field_name). After the replacement is completed, it checks if the parameters are valid. If they are valid, it returns the estimated credits based on the parameters.

  • Error Request Example 1(Some fields are missing in the parameters.):

    {
      "template_id": "676018193025756628",
      "fields": {
        "field_attrs": [
          {
            "node_id": "27",
            "field_name": "text",
            "field_value": "1 girl, amber_eyes"
          }
        ]
      }
    }

    Response:

    {
      "code": 2,
      "message": "can't find [nodeId:fieldName] 25:image in fields parameter"
    }

  • Error Request Example 2: During the processing of this request, the image of node_25 in the obtained template will be set to null. Since this action is invalid, it will return false along with the error reason.

    {
      "templateId": "676018193025756628",
      "fields": {
        "fieldAttrs": [
          {
            "nodeId": "25",
            "fieldName": "image",
            "fieldValue": null
          },
          {
            "nodeId": "27",
            "fieldName": "text",
            "fieldValue": "1 girl"
          }
        ]
      }
    }

    Response:

    {
      "code": 3,
      "message": "Params Valid",
      "details": [
        {
          "@type": "type.googleapis.com/tams_api.ArgumentError",
          "field": "workflow",
          "message": "node id: 25\nclass type: LoadImage\nimage: 字段必填\n"
        }
      ]
    }

  • Correct Request Example:

    {
      "templateId": "676018193025756628",
      "fields": {
        "fieldAttrs": [
          {
            "nodeId": "25",
            "fieldName": "image",
            "fieldValue": "f29036b4-ff7b-4394-8c26-aabc1bdae008"
          },
          {
            "nodeId": "27",
            "fieldName": "text",
            "fieldValue": "1 girl"
          }
        ]
      }
    }

    Response (estimated credits are 1):

    {
      "valid": true,
      "credits": 1
    }

Create Workflow Template Job​

This interface also retrieves the workflow template, then replaces the fields and checks the parameters. After the checking is completed, it creates a new job to generate the diagram. (fieldValue is the media_resource_id obtained after uploading the image)

  • Request Example:

    {
      "request_id": "cc05d4e1a98f8a1438ea6ebcce77a8d5",
      "templateId": "676018193025756628",
      "fields": {
        "fieldAttrs": [
          {
            "nodeId": "25",
            "fieldName": "image",
            "fieldValue": "f29036b4-ff7b-4394-8c26-aabc1bdae008"
          },
          {
            "nodeId": "27",
            "fieldName": "text",
            "fieldValue": "1 girl"
          }
        ]
      }
    }

    request_id is an md5 string generated based on the current timestamp. You can use the following JavaScript script or script in other languages to generate it:

    const crypto = require('crypto')
    const request_id = crypto
      .createHash('md5')
      .update('' + Date.now())
      .digest('hex')
    console.log(request_id)

    Response (You can query the diagram generation status using the returned jobId. The status of the newly created job is CREATED):

    {
      "job": {
        "id": "709385162603889157",
        "status": "CREATED"
      }
    }
